Cybersecurity and Secure KVM 4-Port Modular Secure KM Switch PP4.0 W/ Remote
SKU:F1DN004MOD-KM-4
Cybersecurity and Secure KVM 4-Port Modular Secure KM Switch PP4.0 W/ Remote
- Modular form factor for maximizing desk space
- Supports unique integrated cables for easy deployment
- Designed for NIAP PP PSD 4.0 Compliance
- Supports up to four host computers
- Supports a unique remote-control unit
- Dedicated processors with emulators for every port: Isolated port paths for peripherals prevent data leaks between computers
- Unidirectional data paths: Optical data diodes prevent peripherals from being used to breach systems
- Peripheral management: USB device detection prevents unauthorized peripheral usage
- Anti-tampering and secure labeling: Holographic tamper-evident product label provides visual indication and prevention of tampering
- Customizable port coloring and naming on the remote control: Facilitates port identification and reduces user switching errors
- Fast switching: No keyboard or mouse delays when switching ports, minimal video delay
- Secure packaging: Tamper-evident packaging ensures product is not tampered with during transport
- Belkin F1DN004MOD-KM-4 Modular Secure 4-Port, KM Switch
- 4x Belkin F1DN1MOD-USB-06 USB Cable for KM, 6ft
- Belkin Modular Secure KM Series 4 Channel Remote Control
- 12V, 2.5A Universal Power Supply with Worldwide Adaptors
- Port Naming and Enclave Coloring Labels
- Quick Start Guide and Compliance Documentation
Ports
- 4-USB
Security Features
- Designed for NIAP PP 4.0 Compliance
Storage Temperature
- -4 to 140F
Certifications
- FCC Class A UL CE RoHS ICES RCM
Console Ports
- 0
External Power
- Yes
Form Factor
- Desktop or Remote Mount
Host Ports
- 4
Housing Type
- Diecast Aluminum
Indicator Light Status
- Port Selected Keyboard Mouse CAP Lock NUM Lock SKRL Lock
Keyboard Input
- 1
Keyboard/Mouse Connections
- 2
Keyboard Type
- USB
Local Console Interfaces
- 0
Mouse Input
- 1
Mouse Type
- USB
PC Ports
- 4 - USB
Power Rating
- 12VDC 2.5A
Power Supply Included
- Yes
Power Supply Type
- External
Remote Control Included
- yes
TAA Compliant
- Yes
Input Voltage (AC)
- 100-240
AC Plug Style
- Worldwide Interchangable Mains Connector
Belkin Modular Secure KM Switch Series
Belkin's Modular Secure KM switches pack the latest in Common Criteria and NIAP Protection Profile for Peripheral Switching Devices version 4.0 design requirements in the smallest form factor available. Compatible with legacy and new systems, the Modular series of secure KMs includes a remote control and innovative mount options to allow administrators to craft operator stations to meet security requirements while decluttering the desk. Optical data diodes and embedded peripheral emulation allow operators to safely share peripherals across multiple security enclaves without exposing potential vectors for attack. The US-manufactured and TAA-compliant secure KM series are ideal for use in IT environments that demand rigorous cybersecurity provisions—including government, military, and healthcare applications.
The Belkin Difference
- Smallest footprint for 4 port KM
- Included remote control supports full KM control while decluttering the desk
- Optional mounting hardware supports VESA mounting and under desk mounting
- Common Criteria Certified to NIAP Protection Profile 4.0 to meet the highest security standards
- US-based free technical support
Meets the highest standards for cybersecurity
Ideal for highly sensitive applications that demand isolation between different network security enclaves. The Belkin Modular Secure KM switches utilize optical data diodes and peripheral emulation on each channel to help prevent data leakage between computers while maintaining strict air-gap isolation, even when sharing peripherals.
Accessories facilitate easy installation
Designed for maximum flexibility, the Belkin Modular Secure KM series adapts to fit your particular installation needs. Innovative, optional mounts support under desk and monitor back VESA mounting. All mounts include integrated cable management for a clean and decluttered desk. The included remote control provides full operator control for a streamlined user experience. Extended warranty options allow administrators to synchronize the life-cycle expectancies of the secure KMs with other IT components on an operator’s desk.
Package Includes
- Belkin F1DN004MOD-KM-4 Secure Modular 4-Port, KM Switch
- 4x Belkin F1DN1MOD-USB-06 USB Cable for KM, 6ft / 1.8m
- Belkin Modular Secure KM Series 4 Channel Remote Control
- 12V, 2.5A Universal Power Supply with Worldwide Adaptors
- Port Naming and Enclave Coloring Labels
- Quick Start Guide and Compliance Documentation
Features
- Modular form factor for maximizing desk space
- Supports unique integrated cables for easy deployment
- Designed for NIAP PP PSD 4.0 Compliance
- Supports up to four host computers
- Supports a unique remote-control unit
- Dedicated processors with emulators for every port: Isolated port paths for video, audio, and peripherals prevent data leaks between computers
- Unidirectional data paths: Optical data diodes prevent peripherals from being used to breach systems
- Peripheral management: USB device detection prevents unauthorized peripheral usage
- Anti-tampering and secure labeling: Holographic tamper-evident product label provides visual indication and prevention of tampering
- Customizable port coloring and naming on the remote control: Facilitates port identification and reduces user switching errors
- Fast switching: No keyboard or mouse delays when switching ports, minimal video delay
- Secure packaging: Tamper-evident packaging ensures product is not tampered with during transport
Accessories
Optional Mounts
| Application | Part Number | Description |
|---|---|---|
VESA Monitor Mount |
F1DN-MOD-VMOUNT | Belkin Modular KVM/KM VESA Mount |
Under Desk Mount |
F1DN-MOD-MOUNT | Belkin Modular KVM/KM Under Desk Mount |
Replacement Parts
| Application | Part Number | Description |
|---|---|---|
Remote Control 4 Port |
F1DN-MOD-REM4 | Belkin Modular KVM/KM Replacement Remote Control 4 Port |
PSU |
0401-00811 | Belkin Modular KVM/KM Power Adapter 12V 2.5A, w/Interchangeable mains connector wall mount |
Replacement Host Cable |
F1DN1MOD-USB-06 | Belkin Modular USB Cable for KM, 6ft / 1.8m |
