Cable Characteristic
- Unshielded twisted pair (UTP)
Cable Type
- Bulk cable - CAT 6
Characteristic Impedence
- 100±15Ω @ 1 ~ 550MHz
Conductor Construction
- Bare Stranded Copper
Conductor Resistance
- 93.8Ω/km/20°C max
Conductor Size
- 24AWG x 4pairs
Dielectric Strength
- AC 1.5kV/min
Flame Retardant Test
- CM
Insulation Material
- HDPE
Jacket Diameter
- 5.50±0.20mm
Jacket Material
- PVC
Mutual Capacitance
- 56pF/m max
Propagation Delay
- 536nS/100m max @ 550MHz
Spark Test
- 2.5kV
Standards Compliance
- ISO/IEC 11801; TIA/EIA-568-B.2-1
Structural Return Loss
- 8.6dB min at 550MHz
Belkin CAT6 exceeds requirements of TIA/EIA-568-B.2-1 and ISO/IEC 11801. It is ideal for high-end solutions such as Gigabit Ethernet, 1.2Gbps ATM, and broadband video. This Cable consists of eight stranded 24AWG wires.
