OmniView

PRO3 8-Port USB & PS/2 KVM Switch & PS/2 Cable Bundle

SKU: F1DA108Z-B
OmniView

PRO3 8-Port USB & PS/2 KVM Switch & PS/2 Cable Bundle

OmniView
PRO3 8-Port USB & PS/2 KVM Switch & PS/2 Cable Bundle
SKU: F1DA108Z-B
Find a Reseller

The OmniView PRO3 USB and PS/2 KVM Switch provides easy and dependable server control with extraordinary performance. The Switch enables network administrators to monitor and control up to four, eight, or 16 USB- and PS/2-platform servers from a single console. The PRO Series KVM Switches are the industry's most popular for small to medium server rooms, branch locations, and test and development labs. Designed to grow along with your server network, the Switch can be daisy-chained together using dedicated daisy-chain ports with other OmniView PRO Series or SMB KVM Switches to support up to 256 servers. Belkin PRO3 KVM Cables are required to connect your servers and computers. F1DA108Z-B ships with four 6 foot PS/2 Host connection cables (PN F1D9400-6).

TECHNICAL SPECIFICATIONS

General

Device Type: KVM switch - 8 ports - stackable
Enclosure Type: Desktop
Ports: 8 x KVM port(s)
Keyboard / Mouse Interface: PS/2
Max Resolution: 1920 x 1440 @ 75 Hz
Features: On-Screen Display, firmware upgradable
Status Indicators: Port status

Expansion / Connectivity

Interfaces: Keyboard / video / mouse (KVM) : 8 x 50 pin Centronics, Network stack device : 2 x 25 pin D-Sub (DB-25), 1 x RJ-11 - management, Keyboard : 1 x generic - 6 pin mini-DIN (PS/2 style), Mouse : 1 x generic - 6 pin mini-DIN (PS/2 style), Keyboard : 1 x 4 pin USB Type A, Mouse : 1 x 4 pin USB Type A, Display / video : 1 x VGA - 15 pin HD D-Sub (HD-15)

Power

Power Device: Power adapter - external

Miscellaneous

Width: 17.2 in
Depth: 7.5 in
Height: 1.8 in
Weight: 9.3 lbs
Color: Black
Cables Included: 1 x serial cable, 4 x keyboard / mouse / video cable
Rack Mounting Kit: Included
Manufacturer Selling Program: Belkin B2B

Software / System Requirements

OS Required: SunSoft Solaris 8, Novell NetWare 5.x, Microsoft DOS 5.x or later, Apple MacOS X, Microsoft Windows Server 2003, Red Hat Linux 8.x, Microsoft Windows 95/98/ME/NT/2000/XP, Microsoft Windows Vista

Manufacturer Warranty

Service & Support: 3 years warranty
Service & Support Details: Limited warranty - 3 years

Environmental Parameters

Min Operating Temperature: 32 °F
Max Operating Temperature: 104 °F
Humidity Range Operating: 0 - 80%

Compatibility Information

Designed For: Belkin OmniView Dual-Rail LCD Console



COMPATIBLE CABLES

Dual Port VGA & PS2 Cable
(each cable supports two computers)

Dual Port VGA & USB Cable
(each cable supports two computers)

Daisy Chain Cable
(used to connect multiple Pro3 KVMs and/or Rack Consoles together)
