Secure 4-Port Keyboard/Mouse Switch

SKU: P-F1DN104K-3
Secure 4-Port Keyboard/Mouse Switch

Secure 4-Port Keyboard/Mouse Switch

SKU: P-F1DN104K-3

The Belkin Secure KVM switches are ideal for data-intensive applications where information from multiple sources of varying security classes must be viewed on multiple displays in real time. The Belkin Secure KM switches comply with the latest NIAP Protection Profile Ver. 3.0 (PP3.0) standard. PP3.0 ensures agencies are using the latest security safeguards relating to Keyboard, Pointing Device, and Audio security.

Seamless cursor and keyboard switching (SCS) allows the user to change automatically from one highly isolated computer system to another by simply moving the mouse cursor between display borders, without having to push any buttons. Every system remains visible on its own display(s), continuously and simultaneously, while the Belkin Secure KM keeps the system isolated and secure.

Analysts and operators in defense and intelligence, banking and trading, or complex command and control environments will benefit immediately and immensely from seamless switching via the mouse.

Model F1DN104K-3 supports up to 4 PCs and 16 displays, in a desktop form factor that can also be mounted under the desk.


You can download the Multi-Display Software for KM from our support site.



Device Type: 4-Port, Secure KM
Enclosure Type: Desktop
Video Ports: Up to 16 Monitors, depending on graphic cards used
Keyboard/Mouse: USB
Max Resolution: Baed on graphic card parameters

Console Ports

1x keyboard (USB Type A)
1x mouse (USB Type A)
1x PS/2 keyboard
1x PS/2 mouse
1x audio output (3.5mm female jack)
1x DCU: RJ14

Host Ports

4x keyboard/mouse (USB Type A)
4x audio input (3.5mm Jack)


12.5" (W) x 6.2" (D) x 1.9" (H)
Weight: 4.3 lbs


Power Device: External power adapter
Voltage: 100/240 VAC (+/- 10%), auto-ranging, 50/60Hz, 12VDC/1.5A output

Manufacturer Warranty

3 years service and parts

Environmental Parameters

Min Operating Temperature: 32°F
Max Operating Temperature: 104°F
Operating Humidity Range: 0-80%, non-condensing
Min Storage Temperature: -4°F
Max Storage Temperature: 140°F


Security Accreditation: NIAP Protection Profile Ver. 3.0
Regulatory Compliant Standards: FCC Class B, CE, UL, ICES



USB & Audio
